Rain Bird 1″ Peb Industrial Inline Irrigation Valve – Plastic, Fpt

Description

1 FPT PEB Inline Commercial Irrigation Valve

The PEB Series is our most durable plastic irrigation valve. This industrial-strength glass-filled nylon globe valve is ideal for commercial irrigation applications.

• Durable glass-filled nylon construction with fabric-reinforced rubber diaphragm for long life and reliable performance.
• Globe configuration.
• Normally closed, forward flow design.
• Slow closing to prevent water hammer and subsequent system damage.
• Low flow capability for a wide range of applications.
• One-piece solenoid design with captured plunger and spring for easy servicing. Prevents loss of parts during field service.
• Flow control handle adjusts water flows as needed.
• Manual internal bleed manually operates the valve without allowing water into the valve box; allows pressure regulator to be adjusted without turning the valve on at the controller first.
• Manual external bleed permits flushing debris from the system. Recommended for system start up and after repairs.
• Stainless steel studs molded into the body. Bonnet can be attached and removed more easily and more often without damaging threads.
• Five-year trade warranty.

Specs

• Pressure: 20 to 200 psi (1,4 to 13,8 bar)
• Flow without PRS-D option: 0.25 to 200 GPM (0,06 to 45 m³/h; 0,02 to 12,60 l/s)
• Flow with PRS-D option: 5 to 200 GPM (1,14 to 45 m³/h; 0,32 to 12,60 l/s)
• Temperature: Up to 150°F (66°C)

Electrical Specifications

• 24 VAC 50/60 Hz (cycles per second) solenoid power requirement
• Inrush current: 0.41A (9.9VA) at 60Hz
• Holding current: 0.14A (3.43VA) at 60Hz
• Solenoid coil resistance: 30-39 Ohms, nominal

Options

• Accommodates optional, field-installed PRS-D pressure regulating module to ensure optimum sprinkler performance. Regulates up to 100 psi (6,9 bar)
• Accepts latching solenoid for use with Rain Bird battery-operated controllers up to 150 psi (10,35 bar)
• Compatible with ESP-LXD decoders

Downloads

• PEB Valves Brochure
• PEB and PESB Valves Manual
• PEB and PESB Series Valves Tech Spec
