Description
Sure Throw™ Pop-Up Impact Sprinkler
Ideal for underground installation in landscaping, residential parks and public lawn applications with a Radius of 37′-42′ depending on nozzle used.
Features
- Adjustable to full circle or part circle
- Interchangeable color-coded bayonet nozzles
- Heavy duty plastic closed case with reinforced easy grip ribbed design
- Diffuser screw for fine droplets and throw control
- Double-weighted arm for balance & smooth rotation
- Sand resistant pressure-activated wiper seal
- Excellent distribution uniformity
- Ideal for use in grey water applications
- ST-IS45-TOOL sold separately for maintenance and inner component replacement.
Specs
- Inlet: 1/2″ and 3/4″ female threaded inlet, 1/2″ female threaded side inlet
- Arc adjustment range: 15° to full 360° adjustable
- Flow range: 2.0 – 5.2 GPM (7,6 – 19,9 L/M)
- Pressure rating: 28 – 57 PSI (2,0 – 3,9 Bars)
- Precipitation rate: 0.28 – 0.56 in/hr (7 – 17 mm/hr)
- Radius: 37′ – 42′ (11,3 – 12,8 m)
- Nozzle trajectory: 25°
- Recommended spacing: up to 39′ (12 m)
- Overall height (popped down): 9.4″ (23.9 cm)
- Riser height: 2.6″ (6.5 cm)
Downloads
- Installation Instructions
- Brochure
