Buckner 17023R08 – 1/2” Full Circle MPT Brass Impact – 23° trajectory – #08 Drive Nozzle (parts interchangeable with Rainbird® 20JH)
Designed for agricultural use in center pivots, solid sets, hand lines, crop cooling and frost control, these models of impact sprinklers can also be used in landscape irrigation situations requiring large area coverage.
Specifications
- 1/2″ Male NPT Inlet (National Pipe Thread)
- #08 – 1/8” Nozzle Size Pre-Installed (Other nozzle sizes available but not stocked, please email contact@cheapsprinklers.com to order with different range nozzles)
- Nozzle Thread: 3/8” – 24 UNF
Operating Ranges
- Pressure: 25 to 60 PSI
- Flow: 2.67 to 3.51 GPM
- Throw Diameter: 78 to 82 FT
- Trajectory: 23°
- Rotation: Full Circle
Performance w/ #08 Diameter Nozzle
Features & Benefits
- Solid brass construction
- Stainless steel springs and fulcrum pin
- “Sure Seal®” sand load bearing assembly
- Chemical-resistant bearing seals promote longer lifespan
- 23° angle of trajectory
- Parts interchangeable with Rainbird 20JH
Additional Information
- 17023R Product Page
Other Throw Radius Nozzle options (76′-88′) are available for this product. If you need another nozzle besides the #08 pre-installed option, then please email contact@cheapsprinklers.com for a quote and availability.
